Power：150W
Series：CC LED Driver
Application：High bay light, Stadium light, Square light, Horticulture light, Fish light, Harbor light
Certificate：UL/cUL, Class P, FCC
Warranty：5 years
CC LED Driver
Efficiency up to 91%
Dimming: 0-10V, PWM, Resistor, Timing
Dim-to-Off
Surge protection: CM: 10kV, DM: 6kV
AUX Power：12V/0.3A
Constant Lumen O/P
Optional Standby(STB) Function
Standby Power<1.5W
IP67
Communication function with PC
Type HL, suitable for hazardous locations
Protections: SCP/OTP/UVP
Warranty: 5 years
| Model | AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-150M-56BH | 249-528 | 150 | 22-56 | 36-56 | 0.35-4.2 | 10% | 0.95 | 90% | 90℃ |
| SS-150M-225BH | 249-528 | 150 | 85-215 | 108-215 | 0.1-1.4 | 10% | 0.95 | 91% | 90℃ |
| Reted Input Voltage | 277~480Vac |
| Input Frequency Range | 50/60Hz |
| Max. Pout | 150W |
| Dimension | 221*71*39.6（mm） |
| Carton Dimension | L×W×H =495×385×162(mm) |
| QTY | 14 PCS |
| Net Weight/PC | 1.1kg |
| Gross Weight/Carton | 16.5kg |
