SS-150VH-XX*

SS-150VH-XX*

Product Features

Power：150W

Series：CC LED Driver

Application：High Pole light, High bay light, Stadium light, Horticulture light, Street light, Fish light

Certificate：UL/cUL, ENEC, RCM, CCC, CB

Warranty：5 years

Product Description

CC LED Driver

Consult lmmediately
Specifications
Features
Reference
Parameters
Packing

Efficiency up to 93%

Isolated dimming: 0-10V, PWM, Timing

Programmable

IP67

Protections: SCP/OTP/OVP/OPP

Type HL, suitable for hazardous locations

Surge protection: IEC: CM: 10kV, DM: 6kV

                           ANSI: CM: 6kV, DM: 6kV

Warranty: 8 years

    ModelAC Input Range（Vac）Max. Pout（W）Vout Range（Vdc）Full Power Vout Range（Vdc）Iout（A）THD(Typ.)PF(Typ.)Eff.(Typ.)Max.Tc
    SS-150VH-56B90-30515028-56

    36-56

    		0.7-4.25%0.9893%90℃
    Reted Input Voltage100~277Vac
    Input Frequency Range50/60Hz
    Max. Pout150W
    Dimension165*66*37（mm）
    Carton DimensionL×W×H =495×385×162 (mm)
    QTY14 PCS
    Net Weight/PC0.72kg
    Gross Weight/Carton12kg
