Power：80W
Series：CC LED Driver
Application：Wall washers Flood light, Wall light
Certificate：UL/cUL, TUV, CCC, CE, Class P
Warranty：5 years
CC LED Driver
Efficiency up to 94%
Dimming : 0-10V, PWM, Resistor
Isolated Dim-to-off
AUX Power：12V/0.2A
Standby power<0.5W
Protections: SCP/OTP/OVP
Surge protection: CM: 6kV, DM: 6kV
Warranty: 5 years
| Model | AC Input Range（Vac） | Max. Pout（W） | Vout Range（Vdc） | Full Power Vout Range（Vdc） | Iout（A） | THD(Typ.) | PF(Typ.) | Eff.(Typ.) | Max.Tc |
| SS-80NH-E260* | 90-305 | 80 | 180-260 | 200-260 | 0.28-0.4 | 8% | 0.97 | 94% | 90℃ |
| Reted Input Voltage | 100~277ac |
| Input Frequency Range | 50/60Hz |
| Max. Pout | 80W |
| Dimension | 164*45*34（mm） |
| Carton Dimension | L×W×H =495×385×162 (mm) |
| QTY | 24 PCS |
| Net Weight/PC | 0.372kg |
| Gross Weight/Carton | 13.9kg |
