SS-1000L-N360BH

SS-1000L-N360BH

Product Features

Power：1000W

Series：CC LED Driver

Application：Horticulture light, Square light, High Pole light

Certificate：UL/cUL,CE

Warranty：5 years

Product Description

CC LED Driver

Consult lmmediately
Specifications
Features
Reference
Parameters
Packing

Efficiency up to 97%

Isolated dimming: 0-10V, PWM, Resistor, Timing

Constant Lumen O/P

AUX Power：12V/0.2A

Communication function with PC

IP67

Protections: SCP/OTP/UVP

Standby Power<0.5W

Surge protection:  CM: 6kV, DM: 6kV

Warranty: 5 years

    ModelAC Input Range（Vac）Max. Pout（W）Vout Range（Vdc）Full Power Vout Range（Vdc）Iout（A）THD(Typ.)PF(Typ.)Eff.(Typ.)Max.Tc
    SS-1000L-N360BH180-3051000210-360

    240-360

    		0.7-4.178%0.9596.5%90℃
    Reted Input Voltage200~277Vac
    Input Frequency Range50/60Hz
    Max. Pout1000W
    Dimension368.3*89.5*44.5（mm）
    Carton DimensionL×W×H =495×385×162(mm)
    QTY5 PCS
    Net Weight/PC2.725kg
    Gross Weight/Carton15.1kg
